Airmax 2.5 CFM Shallow Water Pond Aeration System SW20 with (2) 100' Rolls of Airline Aerates up to 1/4 Acre Pond Aerators Pond Aerators

Designed specifically for use in shallow water, the Airmax Shallow Water Series SW20 Pond Aeration System aerates a pond up to a 1/4 surface acre at 6 ft. deep. Providing bottom-diffused aeration in shallow ponds and lakes can provide a unique challenge to pond owners. Less water depth means smaller plate coverage, which translates to a more extensive, more expensive, multi-plate pond aeration kit. The Airmax pond aeration system utilizes multiple plates to provide evenly distributed aeration in shallow water applications without forcing pond owners into large cost-prohibitive aeration units. The Airmax Composite Cabinet houses and protects the SilentAir Compressor from outdoor elements. An integrated cooling system utilizes a ventilation fan with a rain shroud and high-density air intake pre-filter to distribute air evenly throughout the cabinet keeping the interior components clean, cool, and dry. An elevated base protects the aeration hardware and electrical components from flooding and rainwater accumulation, while the removable top ensures quick and easy access for inspection and maintenance. Every Airmax Composite Cabinet comes complete with a pre-wired electrical box and 6 ft. power cord to provide power to the enclosed cooling fan and aeration compressor and is ETL Listed. The heart and soul of each Shallow Water Series Aeration System are a powerful, yet energy-efficient, SilentAir LR Series Linear Diaphragm Compressor. It pushes oxygen through your pond while remaining whisper-quiet and is fitted with an integrated Manifold with Ball Valves to simplify airflow management. It is mounted on vibration-reducing rubber ft. to ensure quiet operation. Each airline is equipped with Quick Disconnects for easy system removal and storage. Designed for maximum oxygen uptake, the ProAir2 Weighted Diffuser incorporates high-efficiency low-maintenance membrane sticks to release tiny oxygen bubbles into the water column. Membrane diffusers possess the synergy of air stones without the headaches of cracking and acid-washing. The ProAir2 Weighted Diffuser has an integrated check valve to prevent back pressure on the compressor. Thick-wall, lead-free construction makes EasySet airline the perfect pond-safe choice. Resistant to rips and tears, EasySet airline is resilient against fishing hooks and foot traffic from swimmers, pets, and wildlife. The 3/8 in. Weighted Airlines is designed to stay submerged underwater and out of sight.

Airmax pond aeration system is perfect for shallow water ponds or beach areas
A single system can aerate a pond up to a 1/4 surface acre at up to 6 ft. deep
ETL Electrical Safety Certification
Extremely efficient linear diaphragm compressor
Airmax ETL composite cabinet comes with a pre-wired electrical box and 6 ft. power cord
SilentAir LR Series linear diaphragm compressor pushes oxygen through your pond while remaining whisper-quiet
ProAir2 weighted diffuser uses high-efficiency low-maintenance membrane sticks to release tiny oxygen bubbles into the water column
EasySet weighted airline resists rips and tears and is guaranteed not to float
Running Amps: 0.43
Volts: 115V
Max Air Flow: 2.5 CFM
Max Diffuser Depth: 6 ft.
Approximate operating cost/month for pond aeration kit: $3.60
10-year warranty on the Airmax Composite Cabinet and a 3-year warranty on electrical components
Innovative sled design keeps the ProAir2 submerged while maintaining an upright position during installation and comes with a 5 year warranty.
3-year warranty on the compressor

Airmax 2.5 CFM Shallow Water Pond Aeration System SW20 with (2) 100' Rolls of Airline Aerates up to 1/4 Acre Pond Aerators Outdoor Living> Pond Care & Accessories> Pond Aerators

Specification	Description
Brand	Airmax
Country of Origin	Made in USA
Aerator Type	Bottom Diffuser Aerators
Air Line Length	200 ft.
Amperage	0.6A
Cord Length	6 ft.
Maximum Airflow Rate	2.5 CFM
Maximum Pond Size	0.25 acre
Maximum PSI	30 PSI
Maximum Recommended Pond Depth	6 ft.
Number Of Outlets	2
Power Type	Electric
Product Height	24 in.
Product Length	25 in.
Product Weight	85 lb.
Product Width	23 in.
Voltage	115V
Warranty	2 Year
Manufacturer PartNumber	600803

Airmax 2.5 CFM Shallow Water Series Pond Aeration System, SW20 with (2) 100 ft. Rolls of Airline Aerates up to 1/4 Acre Specifications expand/collapse Specification Description Brand Airmax Country of Origin Made in USA Aerator Type Bottom Diffuser Aerators Air Line Length 200 ft. Amperage 0.6 A Cord length 6 ft. Maximum Air Flow 2.5 CFM Maximum Basin Size 0.25 acre Maximum PSI 30 PSI Maximum Recommended Basin Depth 6 ft. Number of Outlets 2 Power Type Electric Product Height 24 in. Product Length 25 in. Product Weight 85 lb Product Width 23 in Voltage 115 V Warranty 2 Years Manufacturer Part Number 600803
