California Air Tools 60 gal 6.5 HP 3-Phase Air Compressor Stationary Air Compressors Air Compressors

The CALIFORNIA AIR TOOLS 60065C Ultra Quiet & Oil-Free 60 Gallon ASME Air Compressor is designed to be one of the quietest 6.5 Hp air compressors in the industry having only 85 decibels of sound compared to competitive models. The Powerful 6.5 Hp 3-Phase 230 volt motor-pump operates at 3400 RPM creating up to 20 CFM air flow and is designed to increase duty cycle and allow for longer continuous run operations.* The Oil-Free Quad Piston Pump System is engineered for high performance and durability. The large 60 Gallon ASME Steel Air Tank is just the right size to support a large facility including commercial business, manufacturing operations, autobody shops and other general pneumatics that require air volumes of up to 20 cfm. Designed for the person looking for Power, Oil-Free Air Flow and at Least 30% Less Noise!

Ultra Quiet - 85 decibels
Oil-Free Pump Cleaner air for better tool operation. Less maintenance and Costs.
One tank pressure gauge
1/2" NPT female port. No output pressure regulator, quick connector or air hose included
Condor Pressure Switch
Thermal Overload Protector
120 PSI Maximum Pressure
230 Volt / 60 Hertz / 3-Phase (range 215v to 240v)
Amp Draw - 15 Amps
20 Amp Breaker suggested
Time to fill tank from empty to full - 191 Seconds
Recovery time from 92 PSI to 120 PSI - 35 Seconds
Less heat which dissipates more efficiently
60 Gallon ASME Steel 155 PSI Air Tank
L (32.5") x W (28") x H (60.5")
260 lbs
Manual Drain Valve with Strainer cleanout
Comes complete with (4) Air Filters
Limited Warranty 1 Year

California Air Tools 60 gal 6.5 HP 3-Phase Air Compressor Stationary Air Compressors Tools> Air Compressors & Air Tools> Air Compressors> Stationary Air Compressors

Specification	Description
Brand	California Air Tools
Country of Origin	Imported
Air Delivery SCFM At 40 PSI	20 CFM
Air Delivery SCFM At 90 PSI	17 CFM
Airflow Volume	20 CFM 40 PSI 17 CFM 90 PSI
Air Outlet Size	0.25 in.
Compressor Horsepower	6.5 HP
Compressor Maximum PSI	155 PSI
Compressor Tank Capacity	60 gal
Compressor Type	Oil less
Compressor Voltage	230V
Drain System	Manual Drain
Drive Type	Direct
Features	60 Gallon ASME Certified
Number Of Power Speeds	Single
Power Type	Electric
Primary Color	Gray
Primary Material	Steel
Product Height	60.5 in.
Product Length	32.5 in.
Product Weight	260 in.
Product Width	28 in.
Pump Material	Steel
Tank Orientation	Vertical
Warranty	1 Year Limited Warranty
Manufacturer PartNumber	60065C

California Air Tools 60 gal. 6.5 HP 3 phase Air Compressor Specifications Expand/Collapse Specification Description Brand California Air Tools Country of Origin Imported Air Flow SCFM at 40 PSI 20 CFM SCFM Air Flow at 90 PSI 17 CFM Air Flow Volume 20 CFM 40 PSI 17 CFM 90 PSI Size air outlet 0.25 in. Compressor Power 6.5 HP Compressor Maximum PSI 155 PSI Compressor Tank Capacity 60 gal Compressor Type Oil Free Compressor Voltage 230 V Drain System Manual Drain Drive Type Direct Features 60 gallons ASME Certified Number of Power Speeds Type Single Power Supply Electric Primary Color Gray Primary Material Steel Product Height 60.5 in. Product Length 32.5 in. Product Weight 260 in. Product Width 28 in. Pump Material Steel Reservoir Orientation Vertical Warranty One-Time Limited Warranty an Manufacturer Part Number 60065C
