Chief WP Welded Cylinder 2 in Bore x 8 in Stroke with Eye Rod 1.25 in Rod Diameter 000 PSI Hydraulic Cylinders Tractor Repair & Parts

The Chief 2 in. Bore x 8 in. Stroke WP Welded Cylinder with Pin-Eye Rod is a very versatile welded hydraulic cylinder. The rod end comes with a drilled pin-hole and can easily be customized to fit your rod end of choice. Ideal for construction and agricultural applications as well as other industries like OEM manufacture of trailers, metal fabricating and waste/recycling equipment, you can trust this hydraulic cylinder. SAE 8 O-ring ports means easy hookup, and the cylinder comes functionally tested and pressurized to 1.5 times the normal working pressure to insure performance reliability.

Welded hydraulic cylinder ideal for construction and agricultural applications as well as other industries like OEM manufacture of trailers, metal fabricating and waste/recycling equipment
SAE 8 O-ring ports for easy hookup
For use in double acting hydraulic cylinder or single acting hydraulic cylinder applications
All seals are manufactured to US specifications
3-year limited warranty
Individually poly bagged for ease of transfer
3,000 PSI operating range
Piston: ductile iron with wear ring
Gland: ductile iron, screw-in design with wear ring
Tube: precision honed steel
Rod: hard chrome plated
Base end mount: Steel cross-tube with grease zerk
Tube seal: Buna O-ring with Polytemp hytrel backup
Rod wiper: Urethane, snap-in
Piston seal: Hallite 755 provides prolonged wear resistance with wear ring
Rod end mount: Rod eye drilled
Rod seal: deep polypak with B lip design
Measures 16 in. retracted and 24 in. extended
Column load: 9,420 lb.
Pin diameter of 0.75 in. and rod diameter of 1.25 in.

Note: This product may require up to 2 additional days for order processing prior to shipping

Chief WP Welded Cylinder 2 in Bore x 8 in Stroke with Eye Rod 1.25 in Rod Diameter 000 PSI Hydraulic Cylinders Farm & Ranch> Tractor Parts & Accessories> Tractor Repair & Parts> Tractor Hydraulics> Hydraulic Cylinders

Specification	Description
Brand	Chief
Country of Origin	Imported
Bore Diameter	2 in.
Brand Compatibility	Universal
Compatibility	Varies
Extended Length	24 in.
Hydraulic Cylinder Type	Welded
Maximum Operating Pressure	3,000 PSI
Maximum Weight Capacity	9,420 lb.
Model Compatibility	Most applications
Package Quantity	1
Pin Diameter	0-3/4 in.
Port Size	SAE 8
Primary Material	Steel
Product Height	2.5 in.
Product Length	8 in.
Product Weight	14 lb.
Product Width	1.25 in.
Retracted Length	16 in.
Rod Diameter	1-1/4 in.
Stroke Distance	8 in.
Warranty	3 Year
Manufacturer PartNumber	287207

Chief 2 in. Bore x 8 in. Stroke WP Welded Cylinder with Pin-Eye Rod, 1.25 in. Rod Dimeter000 PSI Specifications expand/collapse Specification Description Brand Primary Country of Origin Imported Bore Diameter 2 in. Brand Compatibility Universal Compatibility Varies Extended Length 24 in. Hydraulic Cylinder Type Welded Maximum Operating Pressure 3,000 PSI Maximum Weight Capacity 9,420 lbs. Model Compatibility Most Applications Package Quantity 1 Pin Diameter 0-3/4 in. Port Size SAE 8 Main Material Steel Product Height 2.5 in. Product length 8 in. Product weight 14 lbs. Product width 1.25 in. Retracted length 16 in. Shank diameter 1-1/4 in. Stroke Distance 8 in. 3 year warranty Manufacturer part number 287207
