JET Electric Chain Hoist 3 Ton 20 Feet Lift 115V/230V Single Phase Electric Hoists Ceiling Hoists

The JET 3 Ton 20 ft. Lift Electric Chain Hoist combines safety and durability to operate in commercial and industrial applications. All models incorporate a slip clutch overload protection mechanism that prevents the hoist from lifting damaging loads above its rated capacity. They are available in single or three phase configurations to suit your electrical needs. Single phase models have a thermal overload protection design that keeps the hoist from overheating, while the three phase models feature a reverse phase relay that protects the hoist from incorrect wiring. The industry proven DC electro-magnetic brake increases safety by holding the load even when power is interrupted. The maintenance-free gear train incorporates a sealed oil bath, for reliability and durability. The JET SSC series electric hoist is available in 1/2 ton to 5 ton capacities with standard lifts of 10, 15, and 20 feet (custom lifts available).

Overload Protection- Slip Clutch design prevents the hoist from lifting damaging loads above its rated capacity
Thermal Overload Protection- Protects the hoist from overheating in low voltage situations
DC Electro-Magnetic Brake- An industry-proven safety feature that secures the load even if power is interrupted to the hoist
Limit Switches- Upper and lower limiting switches increase safety by preventing the load chain from over traveling
Sealed Gear Train- Maintenance-free gear train incorporates a sealed oil bath that eliminates upkeep
Grade 80 Load Chain- Grade 80 black oxide coated load chain for durability
Control Pendant- 24 volt push button controller with cable strain relief system for durability and reliability in industrial and commercial settings

JET Electric Chain Hoist 3 Ton 20 Feet Lift 115V/230V Single Phase Electric Hoists Home Improvement> Moving & Lifting> Ceiling Hoists> Electric Hoists

Specification	Description
Brand	JET
Country of Origin	Imported
Chain Length	8 mm
Features	Black oxide coated load chain
Lift Assist Ratio	0
Lift Height	20 ft.
Maximum Pull Length	20 ft.
Maximum Weight Capacity	3 Ton
Primary Material	Steel
Product Height	18.11 in.
Product Length	22.44 in.
Product Weight	246 lb.
Product Width	20.87 in.
Warranty	2 Year
Manufacturer PartNumber	312000

JET 3 Ton 20 ft. Lift Electric Chain Hoist, 115V/230V, 1 Ph Specifications expand/collapse Specification Description Brand JET Country of Origin Imported Chain Length 8mm Features Black Oxide Coated Lift Chain Lift Assist Ratio 0 Lift Height 20ft Maximum Pull Length 20ft Weight Capacity maximum 3 tons Main material Steel Product height 18.11 inches. Product length 22.44 in. Product weight 246 lbs. Product width 20.87 in. 2 year warranty Manufacturer part number 312000
