K2 Pumps SPA05001VDK 1/2 HP Cast Aluminum Sump Pump with Direct Vertical Switch Sump Pumps Farm & Ranch

The K2 Pumps 1/2 HP sump pump with direct-in vertical float switch, discharges 4100 GPH at 0 ft., with a maximum lift of 29 ft. The motor housing is constructed of epoxy-coated aluminum, which dissipates heat and promotes efficient motor cooling. This pump is ideal for applications that require a rugged submersible sump pump. The energy-efficient, oil-filled PSC motor provides continuous lubrication and extends the life of the pump.

Constructed of epoxy-coated aluminum
Removes water at 4100 GPH at 0 ft. of lift, Maximum lift of 29 ft.
Direct-in vertical float switch for automatic operation
Operates in basins 10 in. in diameter or larger
Top suctions design filters debris and handles up to 1/4 in. solids
1-1/2 in. or 1-1/4 in. (with adapter) FNPT Discharge size
Comes with a 10 ft. power cord
1 Year Warranty

K2 Pumps SPA05001VDK 1/2 HP Cast Aluminum Sump Pump with Direct Vertical Switch Sump Pumps Farm & Ranch> Tanks & Pumps> Water Pumps> Sump Pumps

Specification	Description
Brand	K2 Pumps
Country of Origin	Imported
Amperage	6.5 Amp
Basin Diameter	10 in.
Body Material	Cast aluminum
Compatible Pipe Material	PVC
Discharge Connection	Threaded Female
Discharge Port Diameter	1-1/2 in.
Discharge Rate at 0 ft.	68 GPM
Discharge Rate at 10 ft.	58 GPM
Engine Displacement	0 N/A
Features	1-1/2 in. or 1-1/4 in. (with adapter) female NPT discharge for easy installation without any plumbing changes
Horsepower	1/2 HP
Hose Diameter	1-1/2 in.
Impeller Material	Thermoplastic
Inlet Connection	None
Inlet Diameter	4.85 in.
Maximum Flow Rate	68 GPM
Maximum Head Lift	29 ft.
Maximum Operating Pressure	0 N/A
Maximum Operating Temperature	95 deg.
Maximum Solids Diameter	0.25 in.
Maximum Suction Lift	29 ft.
Minimum Operating Pressure	0 N/A
Minimum Operating Temperature	32 deg.
Power Cord Length	10 ft.
Power Type	Corded/Plug-in
Product Height	11 in.
Product Length	7.88 in.
Product Weight	9.17 lb.
Product Width	8.88 in.
Pump Mechanism	Centrifugal
Motor Type	Permanent Split Capacitor (PSC)
Switch-Off Height	3.5 in.
Switch-On Height	6.7 in.
Voltage	115 V
Warranty	1 Year
Manufacturer PartNumber	SPA05001VDK
