3 Phase Electric Chain Hoist 1/2 Ton Capacity 10 Feet Lift JET Electric Hoists Ceiling Hoists

Get the 1/2-Ton Electric Chain Hoist with 3-Phase 10 ft. Lift. JET SSC Series Electric Hoists combine safety and durability to operate in commercial and industrial applications. All models incorporate a slip clutch overload protection mechanism that prevents the hoist from lifting damaging loads above its rated capacity. They are available in single or three phase configurations to suit your electrical needs. Single phase models have a thermal overload protection design that keeps the hoist from overheating, while the three phase models feature a reverse phase relay that protects the hoist from incorrect wiring. The industry proven DC electro-magnetic brake increases safety by holding the load even when power is interrupted. The maintenance-free gear train incorporates a sealed oil bath, for reliability and durability. The JET SSC Series Electric Hoist is available in 1/2-Ton to 5-Ton capacities with standard lifts of 10, 15, and 20 ft. (custom lifts available). Not rated or designed for outdoor use or wet environments.

Hoist has a 24V push button controller with cable strain relief system for lasting durability and reliability
All steel construction for long-term strength
NEMA 4X compliant push button control pendants
Durable powder coat finish offers lasting scratch resistance over many uses
Electric chain hoist features upper and lower limiting switches to increase safety by preventing the load chain from over traveling
Maintenance-free gear train incorporates a sealed oil bath that eliminates upkeep
Thermal overload protection
Safety switch that protects the hoist from incorrect wiring of the power supply is included
1,000 lb. capacity
Motor: 1-1/3 HP, 460V, 3 phase

3 Phase Electric Chain Hoist 1/2 Ton Capacity 10 Feet Lift JET Electric Hoists Home Improvement> Moving & Lifting> Ceiling Hoists> Electric Hoists

Specification	Description
Brand	JET
Country of Origin	Imported
Features	Powder-Coated
Horsepower	1.33 HP
Lift Assist Ratio	0
Lift Height	10 ft.
Maximum Pull Length	10 ft.
Maximum Weight Capacity	1,000 lb.
Phase	Triple
Primary Material	Steel
Product Height	15.2 in.
Product Length	21.1 in.
Product Weight	102.0 lb.
Product Width	16.4 in.
Voltage	460V
Warranty	2 Year
Manufacturer PartNumber	123100

JET 1/2 Ton Capacity 10 ft. Lift 3-Phase Electric Chain Hoist Specifications Expand/Collapse Specification Description Brand JET Country of Origin Imported Features Powder Coated Power 1.33 HP Lift Assist Ratio 0 Lift Height 10 Feet Maximum Pull Length 10 Feet Maximum Weight Capacity 1,000 lbs Phase Triple Material main Steel Product height 15.2 inches. Product length 21.1 in. Product weight 102.0 lbs. Product width 16.4 in. Voltage 460 V Warranty 2 years Manufacturer part number 123100
