California Air Tools 1 HP 10 gal Ultra Quiet Oil-Free Air Compressor with Air Dryer CAT-10010LFDCAD Stationary Air Compressors Air Compressors
The Ultra Quiet, Oil-Free Air Compressor is designed to be one of the quietest 1.0 horsepower air compressors in the industry having only 60 decibels of sound. The powerful 1 HP motor operates at only 1400 RPM creating less noise, vibration and wear. The CAT-MP100LF Motor/Pump is tested for a minimum pump life of 4000 hours before service with 30% more life before repair The Oil-Free Dual Piston Pump System is engineered for longevity, high performance and durability. The large 10.0-gal. steel air tank is only 75 lb. The Air Dryer is specially designed to remove the water vapor from the air to protect sensitive tools and machinery. The aftercooler is a heat exchanger for cooling the discharge air from the air compressor. The water vapor from the compressed air is condensed into liquid form and pushed into the Air Dryer. This air compressor is ideal for anyone working inside (office, shop, store, warehouse or home) where noise is a major issue.- Only 60 Decibels!
- Oil-Free Pump Cleaner air for better tool operation and less maintenance costs.
- Two pressure control gauges
- One - 1/4 Industrial female quick connector
- Thermal Overload Protector
- 125 PSI Maximum Pressure
- Kick On Pressure 90 PSI - Kick Off Pressure 125 PSI
- 110v / 60 Hz
- Low Amp Draw - Only 7.6 Amps
- Tank fill rate from empty to full 4 minutes
- Duty Cycle - 70/30
- Maximum continuous running 30-60 min. (Depending PSI & CFM)
- 75 lb. L (16 in.) x W (23 in.) x H (32 in.)
- Air Dryer - Includes Activated Alumina desiccant with a 4000-hour life.
- Aftercooler (condenser)
- 1 Year Limited Warranty
California Air Tools 1 HP 10 gal Ultra Quiet Oil-Free Air Compressor with Air Dryer CAT-10010LFDCAD Stationary Air Compressors Tools> Air Compressors & Air Tools> Air Compressors> Stationary Air Compressors
| Specification | Description |
|---|---|
| Brand | California Air Tools |
| Country of Origin | Made in USA |
| Air Delivery SCFM At 40 PSI | 4 CFM |
| Air Delivery SCFM At 90 PSI | 3 CFM |
| Airflow Volume | 4 CFM |
| Air Outlet Size | 1/4 in. |
| Amperage | 7.6 Amp |
| Compressor Horsepower | 1 HP |
| Compressor Maximum PSI | 125 PSI |
| Compressor Tank Capacity | 10 gal |
| Compressor Type | Oil less |
| Compressor Voltage | 110V |
| Connection Type | Quick Connect |
| Decibel Rating | 60 dB |
| Drain System | EZ-1-2321 Auto Drain Valve |
| Drive Type | CAT-MP100LF Motor/Pump |
| Features | Ultra Quiet only 60 Decibels |
| Maximum RPM | 1,400 RPM |
| Phase | Single |
| Number Of Power Speeds | Single |
| Number Of Wheels | 0 |
| Power Type | Electric |
| Primary Color | Brown |
| Primary Material | Steel |
| Product Height | 32 in. |
| Product Length | 16 in. |
| Product Weight | 76 lb. |
| Product Width | 23 in. |
| Pump Life | 4,000 hr. |
| Pump Material | Steel |
| Stage Type | Single-Stage |
| Tank Fill Time | 4 min. |
| Tank Orientation | Vertical |
| Warranty | 1 Year Limited |
| Manufacturer PartNumber | CAT-10010LFDCAD |
