Chief 3 625 PSI G Series Control Valve 10 GPM 1 Spool SAE 10 Inlet/Outlet Open Center Hydraulic Valves & Manifolds Tractor Repair & Parts

The Chief 3,625 PSI G Series Control Valve offers a motor spool and a 4-way, 3-position motor center. The spool valve features an SAE 10 outlet and an SAE 8 work port to help make your job quicker and easier. You can expect the control valve to provide you up to 3,625 PSI of working pressure, more than enough for most applications.

PSI: 3,625
Versatile control valve with 3-position spring center action
GPM: 10
Spool valve with 1 motor spool
Work port: SAE 8
Action: 3-position spring center
Outlet Port: SAE 10
MFG part number: P40-D1-SKZ1
Valving: 4-way 3 position motor center

Chief 3 625 PSI G Series Control Valve 10 GPM 1 Spool SAE 10 Inlet/Outlet Open Center Hydraulic Valves & Manifolds Farm & Ranch> Tractor Parts & Accessories> Tractor Repair & Parts> Tractor Hydraulics> Hydraulic Valves & Manifolds

Specification	Description
Brand	Chief
Country of Origin	Imported
Brand Compatibility	Other
Compatibility	Most application
Inlet Size	SAE 10
Inlet Type	N/A
Maximum Flow Rate	10 GPM
Maximum PSI	3,625 Max
Model Compatibility	Most application
Number Of Directional Control Positions	3
Outlet Size	SAE 10
Outlet Type	N/A
Primary Material	Metal
Product Height	N/A
Product Length	N/A
Product Weight	5.5 lb.
Product Width	N/A
Manufacturer PartNumber	220952

Chief 3,625 PSI G Series Control Valve, 10 GPM, 1 Spool, SAE 10 Inlet/Outlet, Open Center Specifications Expand/Collapse Specification Description Brand Main Country of Origin Imported Brand Compatibility Other Compatibilities Most Applications Inlet Size SAE 10 Inlet Type N/A Maximum Flow 10 GPM Maximum PSI 3,625 Maximum Model Compatibility Most Applications Number of Directional Control Positions 3 SAE Output Size 10 Output Type N/A Primary Material Metal Product Height N/A Product Length N/A Product Weight 5.5 lbs Product Width N/A Product Part Number manufacturer 220952
