ECO-FLO Products Inc 1 HP Cast Iron Electric Irrigation Pump 115/230 V 56 GPM EFLS10 Utility Pumps Farm & Ranch

The ECO-FLO fast, self priming, heavy duty pump is constructed of rugged cast iron and corrosive resistant thermoplastic ideal for lawn sprinkling applications.

Heavy duty 1, 1-1/2, and 2 HP motors, designed for continuous operation.

ECO-FLO Products Inc 1 HP Cast Iron Electric Irrigation Pump 115/230 V 56 GPM EFLS10 Utility Pumps Farm & Ranch> Tanks & Pumps> Utility Pumps

Specification	Description
Brand	ECO-FLO Products Inc.
Country of Origin	Imported
Amperage	17 Amp
Body Material	Cast iron
Compatible Pipe Material	PVC
Discharge Connection	Threaded Female
Discharge Diameter	1.5 in.
Discharge Rate at 0 ft.	60 GPM
Discharge Rate at 10 ft.	52 GPM
Engine Displacement	0CC
Features	Heavy duty motor designed for continuous operation, stainless steel shaft, heavy-duty bearings and open drip-proof design. Dual voltage 115/230V. 1 1/2 in. suction and discharge pipe size
Horsepower	1 hp
Hose Diameter	0 in.
Impeller Material	Plastic
Inlet Connection	Threaded Female
Inlet Diameter	1.5 in.
Maximum Flow Rate	56 GPM
Maximum Head Lift	20 ft.
Maximum Operating Pressure	40 PSI
Maximum Operating Temperature	104 deg. F
Maximum Suction Lift	20 ft.
Minimum Operating Pressure	10 PSI
Minimum Operating Temperature	32 deg. F
Power Type	Electric
Product Height	10 in.
Product Length	20 in.
Product Weight	62 lb.
Product Width	10 in.
Motor Type	PSC
Utility Pump Type	Sprinkler
Voltage	115,230V
Warranty	2 Year
Manufacturer PartNumber	EFLS10

ECO-FLO Products Inc. 1 HP 115/230V Electric Cast Iron Irrigation Pump, 56 GPM, EFLS10 Specifications expand/collapse Specification Description Brand ECO-FLO Products Inc. Country of Origin Imported Amperage 17A Body Material Cast Iron Pipe Material PVC Compatible Discharge Connection Female Threaded Discharge Diameter 1.5 in. Discharge flow at 0 ft. 60 GPM Discharge rate at 10 ft. . Motor Displacement 52 GPM 0CC Features Heavy-duty motor designed for continuous operation, stainless steel shaft, heavy-duty bearings and open drip-proof design. Dual voltage 115/230V. 1 1/2 in. Suction and discharge pipe size Power 1 hp Pipe diameter 0 in. Impeller Material Plastic Inlet Fitting Female Threaded Inlet Diameter 1.5 in. Maximum flow 56 GPM Maximum head lift 20 feet Maximum operating pressure 40 PSI Maximum operating temperature 104 degrees. F Maximum suction height 20 feet. Minimum operating pressure 10 PSI Minimum operating temperature 32 deg. F Type of foodelectrical installation Product height 10 in. Product length 20 in. Product weight 62 lbs. Product width 10 in. Motor Type PSC Util City Pump Type Irrigation Voltage 115.230 V Warranty 2 Years Manufacturer Part Number EFLS10
