FLO-RAPIDE 10.5 gal Diesel Exhaust Fluid (DEF) Container Fuel Transfer Tank Accessories Truck & Automotive

The FLO-FAST 10.5 gal. Diesel Exhaust Fluid (DEF) Container was designed to be used with DEF and a variety of other fluids for general purposes and commercial applications. The rotationally-molded polyethylene constructed diesel fluid container combined with dual handles make it ultra-functional and exceptionally durable; thus allowing it to hold up in any type of environment. The diesel exhaust container will provide the utility and function necessary for all your portable DEF transfer operations.

Dual handle container is compatible with many types of fluids from DEF to water to chemicals
Dimensions of the diesel fluid container: 11.5 in. x 11 in. x 32 in. tall with cap
Rotationally molded polyethylene offers durability
Container holds 10.5 gal. of fluid with indicators in Gallons and Liters, which is visible on both sides of the can
Heavy-duty and ultra durable rotationally-molded container provides consistent wall thickness throughout the jug
3 in. opening with a solid-plastic cap and large internal O-ring, providing maximum seal
Dual handles on the top for easy lifting and maneuverability
Molded-in, female stainless steel insert, combined with male vent valve to provide ample airflow when utilizing the FLO-FAST pumps
Stainless steel vent construction delivers enhanced strength
Cap includes an EPDM O-ring
Handle grip on the bottom of the container
Validate fluid compatibility with EPDM material; always make sure to validate fluid compatibility with materials in this product
Diesel exhaust container is made in the USA
Comes in white
Backed by a 1 year warranty
For experienced professionals in motorsports, offroad, marine, agriculture and industrial markets
Can be used for storage and transport of feed, water, attractants and other fluids
Natural/white container: if used with hazardous fluids, it's required to have additional hazmat labeling for the contents/fluid
Before pumping and drawing: make sure safety tether squeeze clamp is attached to the equipment, utility vehicle or boat before transferring fluid; the purpose of the squeeze clamp is to ensure the hose will stay in the filler opening
Pumping and drawing: when pumping or drawing fluid with the FLO-FAST pump, you must properly vent the system; turn vent counterclockwise (turns into container) to open vent and clockwise (vent turns outward) to close the vent; if you are using the FLO-FAST pump with fluids that do not lubricate, over time you may have to prime the pump if you are trying to pump or draw fluid with a dry pump; you may need to prime the pump if you are trying to draw or suck fluid from more than 7 ft. away (each pump comes with 5 ft. of hose); 5 ft. accessory extension is for pumping purposes; if you are pumping or drawing at a rate of more than 60 revolutions per minute, you run the risk of over pressurizing the pump
When fluid transfer is complete: carefully raise the line out of the fluid opening and let any residual fluid drain back into the system container; do not set the hose down until all of the fluid has drained back into the container; place plug on the tether line into the aluminum tube to seal the hose; before removing the pump system from containers, make several counterclockwise rotations to pull residual fluid out of the pump housing; leave the pump on container for a minimum of 15 minutes to ensure any fluid inside the pump housing drains back into the container; always remove the FLO-FAST pump from the container and place the original cap back onto the container to properly seal and store fluid; to eliminate any person from pumping fluid accidentally, do not store the FLO-FAST pump in the container; always return the pump and system to a safe area where children/others do not have access to it
Transporting: never transport without securing the containers; do not rest or lay the containers on their side
Storage: DEF should be stored in a cool, dry, well-ventilated area, out of direct sunlight; while the optimum storage temperature is up to 77 degrees F (25 degrees C), temporary exposure to higher temperatures has little to no impact on the quality of DEF; do not store jugs outside or in the sunlight
Never allow individuals under licensed age to use the FLO-FAST pump or system; never let anyone use the FLO-FAST system or containers that has not read this instruction sheet in full; do not transport the FLO-FAST pump while it is in a container; only use the FLO-FAST pump on industry standard largemouth containers; pouring from these containers can be dangerous and is not recommended with a volatile or combustible fluids; for that reason, we have designed the FLO-FAST pump system to safely transfer these fluids; do not use the FLO-FAST pump on any container that does not fit the FLO-FAST pump; if you choose to use FLO-FAST with any type of volatile fluid like gasoline, methanol, kerosene or any harmful chemical, do not inhale vapors; when filling a container, always place the container on the ground; to allow for fluid expansion, do not overfill the container beyond manufacturers specified levels; if any component breaks on the FLO-FAST portable fluid transfer pump or system, do not use until you have replaced all of the broken components

FLO-RAPIDE 10.5 gal Diesel Exhaust Fluid (DEF) Container Fuel Transfer Tank Accessories Truck & Automotive> Fuel Transfer Tanks & Pumps> Fuel Transfer Tank Accessories

Specification	Description
Brand	FLO-FAST
Country of Origin	Made in USA
Features	Liquid Transfer
Fill Opening Diameter	3 in.
Maximum Fill Capacity	10.5 gal.
Maximum Tank Fill Capacity	10.5 gal
Outlet Diameter	3 in.
Primary Color	White
Primary Material	Polyethylene
Product Height	31.625 in.
Product Length	11.37 in.
Product Weight	9 lb.
Product Width	11.37 in.
Warranty	1 Year
Manufacturer PartNumber	10503-D

FLO-FAST 10.5 gal. Diesel Exhaust Fluid (DEF) Container Specifications expand/collapse Specification Description Brand FLO-FAST Country of Origin Made in USA Features Liquid Transfer Filling Opening Diameter 3 in. Maximum fill capacity 10.5 gal. Maximum Tank Fill Capacity 10.5 gal Outlet Diameter 3 in. Primary Color White Primary Material Polyethylene Product Height 31.625 in. Product Length 11.37 in. Product Weight 9 lb. Product Width 11.37 in. Warranty 1 Year Part Number manufacturer part 10503-D
