Maxim Single Acting Snow Plow Cylinder 2 in Bore x 16 in Stroke 2 in Shank Diameter 288515 Hydraulic Cylinders Tractor Repair & Parts
The Maxim 2 in. Bore x 16 in. Stroke Single-Acting Snowplow Cylinder features pin holes at both its base and rod end. This single acting hydraulic cylinder has two 1/4 ports 90 degrees apart to accommodate variable installation requirements. Hard work is never fun, that's why this hydraulic cylinder has been made with exacting precision to help make your work easier and faster!- Two 1/4 ports 90 deg apart; 1 parallel to and 1 perpendicular to the pins in order to accommodate variable installation requirements
- Max PSI: 2,500
- Pin hole center in the single acting hydraulic cylinder is 11/16 in. from rod end
- Painted black
- Hydraulic cylinder measures 23.63 in. retracted and 39.63 in. extended
- Pin diameter of 1 in. and rod diameter of 2 in.
- 1 year warranty
Maxim Single Acting Snow Plow Cylinder 2 in Bore x 16 in Stroke 2 in Shank Diameter 288515 Hydraulic Cylinders Farm & Ranch> Tractor Parts & Accessories> Tractor Repair & Parts> Tractor Hydraulics> Hydraulic Cylinders
| Specification | Description |
|---|---|
| Brand | Maxim |
| Country of Origin | Imported |
| Bore Diameter | 2 in. |
| Brand Compatibility | Universal |
| Compatibility | 4 in. |
| Extended Length | 39.63 in. |
| Hydraulic Cylinder Type | Snowplow |
| Maximum Operating Pressure | 3,000 PSI |
| Maximum Weight Capacity | 20 lb. |
| Model Compatibility | Universal |
| Package Quantity | 1 |
| Pin Diameter | 1 in. |
| Port Size | 1.4 NPT |
| Primary Material | Steel |
| Product Height | N/A |
| Product Length | N/A |
| Product Weight | 20 lb. |
| Product Width | N/A |
| Retracted Length | 23.63 in. |
| Rod Diameter | 2 in. |
| Single/Double Acting | Single acting |
| Stroke Distance | 16 in. |
| Warranty | 1 Year |
| Manufacturer PartNumber | 288515 |
