Pacer LCT CMXX Engine-Driven Gasoline Chemical and Clean Water Transfer Pump 200 GPM Transfer Pumps Farm & Ranch

Pacer's S' Series Self-Priming Centrifugal pumps are lightweight and chemically resistant for general service on water, salt water, waste water, agricultural chemicals, and mild acids and bases. They feature stainless steel internal and external fasteners and EPDM elastomers The pumps are molded of tough, engineered thermoplastics. All pumps include a built-in check valve, feature easy servicing and during pumping, a self-cleaning double volute keeps pump free of settled solids. It features a 2 in. port on the inlet and discharge connections with NPT threads for easy connections. It is powered by a LCT CX Pro, 208cc Commercial duty gas engine. Rates of up to 200 GPM or 120 ft. TDH. Please Call Pacer with any chemical compatibility or application questions.

2 in. Suction & Discharge ports
200 Max GPM
120 ft. Max TDH
Suction Lift to 25 ft.
Built in check valve
Tough glass reinforced polyester
Stainless steel hardware
LCT CX Pro Gasoline engine- Commercial Duty
208 CC gasoline engine
LCT Feature - Cast iron Cylinder liner, Viton Oil Seal, Dual ball bearings, Forged steel crankshaft and camshaft
LCT Feature - Low Oil shut-off for extra protection
LCT Feature - Meets Carb & EPA standards
LCT Feature - Large capacity fuel tank
For use in Aquaculture, Agriculture, Marine and Industrial
Molded & Assembled in the USA (Lancaster, PA)

1-year Limited manufacturer warranty

Pacer LCT CMXX Engine-Driven Gasoline Chemical and Clean Water Transfer Pump 200 GPM Transfer Pumps Farm & Ranch> Tanks & Pumps> Transfer Pumps

Specification	Description
Brand	Pacer
Country of Origin	Made in USA
Body Material	Polyester
Compatible Pipe Material	Plastic
Discharge Connection	Threaded Female
Discharge Diameter	2 in.
Discharge Rate at 0 ft.	200 GPM
Discharge Rate at 10 ft.	180 GPM
Engine Brand	LCT
Engine Displacement	208cc
Features	200 GPM Max, 25 ft. suction lift, TDH 120 ft. Max, Built in Check Valve, Tough glass reinforced polyester, EPDM Elastomers, 208CC LCT Commercial Duty Gasoline Engine, Meets carb and EPA emission standards, Forged Crankshaft and Camshaft,
Hose Diameter	2 in.
Inlet Connection	Threaded Female
Inlet Diameter	2 in.
Maximum Flow Rate	200 GPM
Maximum Head Lift	120 ft.
Maximum Operating Pressure	48 PSI
Maximum Operating Temperature	130 deg. F
Maximum Suction Lift	25 ft.
Minimum Operating Pressure	0 N/A
Minimum Operating Temperature	-10 deg. F
Power Type	Gas
Product Height	16 in.
Product Length	21 in.
Product Weight	49 lb.
Product Width	18 in.
Pump Mechanism	Centrifugal
Motor Type	Gasoline
Warranty	1 Year Limited
Manufacturer PartNumber	P-58-12U4-CX208

Pacer Gas-Powered Chemical and Clear Water Transfer Pump LCT CMXX Engine Driven, 200 GPM Specifications expand/collapse Specification Description Brand Pacer Country of Origin Made in USA Body Material Polyester Compatible Hose Material Plastic Discharge Connection Female Threaded Discharge Diameter 2 in. Discharge Rate at 0 ft 200 GPM Discharge Rate at 10 ft 180 GPM Engine Brand LCT Engine Displacement 208 cc Features 200 GPM Max, 25 ft Suction Lift, TDH 120 ft Max, Built-in Check Valve, Reinforced Polyester durable glass, EPDM elastomers, 208CC LCT gasoline engine for commercial use, meets carburetor and EPA emission standards, forged crankshaft and camshaft, Pipe diameter 2 in. Inlet fitting Female thread Inlet diameter 2 in. Maximum flow 200 GPM Maximum head lift 120 feet. Maximum operating pressure 48 PSI Maximum operating temperature 130 deg. F Maximum suction height 25 feet Minimum operating pressure 0 N/A Operating temperatureminimum -10 deg. F Power Type Gas Product Height 16 in. Product length 21 in. Product weight 49 lbs. Product width 18 in. Centrif Pump MechanismEngine Type Ugal 1 Year Limited Gasoline Warranty Manufacturer Part Number P-58-12U4-CX208
