Raymarine Cyclone Pro radar with 6' open array and 15m cables Marine Navigation & Instruments
With a powerful 110-watt solid-state transmitter, Cyclone Pro delivers superior target separation and increased long-range resolution using CHIRP pulse compression and beam sharpening technology. The Cyclone Pro's increased power output is equivalent to a 12-kilowatt magnetron radar and gives the Cyclone Pro a range of up to 96 nautical miles. The Cyclone Pro model features innovative detection capabilities including Cyclone Bird Mode, RangeFusion™ technology and 60 RPM high-speed imaging.
Raymarine T70496 Attributes- Radar Type : Open Array
- Size: 6 feet of array
- Range: 96 nautical miles
- Rotation speed: 12 to 60 rpm
- Output power: 110 watts
- Dimension: 15.27 inches length x 14.17 inches width x 13.18 inches height
- Input voltage: 12 volts to 24 volts
- Beam width: 1.32 degrees horizontal/25 degrees vVertical
- Color: White
- Waterproof Rating: IPX6 Waterproof Rating
- Includes: Radar Pedestal/Voltage Converter/Power Supply Cable/Data Cable /Mounting kit
- Inspired by airplane wings: designed for extreme conditions with best-in-class 100 knot wind rating
- The Cyclone's lower profile allows for greater boat architecture flexibility and more adaptable installation options
- The Cyclone automatically tracks up to 50 targets using the same Arpa technology technology trusted by the United States Coast Guard
- RangeFusion™ technology combines short and long pulses into a single, high-clarity radar image, simultaneously providing exceptional short- and long-range targets.
- Fast 60 RPM rotation speed provides 360 degree awareness andprecise target tracking in real time. -Time
- Doppler target tracking simplifies interpretation of dangerous and safe targets for added safety
- Innovative pedestal design conceals cable connections for cleaner installation
- Cyclone's 6-foot option provides superior target separationIon detection and range
- 2-year limited warranty
- Cyclone Cyclone Pro 87402 Installation Instructions (Rev 5) (EN).pdf
- Raymarine-Global-Limited- Warranty-01-Jul-17-rev1-0.pdf
- Cyclone Cyclone Pro Installation Instructions 87402 (Rev 5) (EN).pdf
- Open Array 36 inch E70628 E70620 E70621 E70622 2D PDF.pdf
- Open Array 36 inch E70628 E70620 E70621 E70622 2D PDF.pdf
Cyclone Pro 110 W radar with 6' open arrayand 15M cables
SOLID-STATE OPEN RADAR ARRAY
Ultimate expression of design, robust performance and knowledge of Unrivaled situation, Cyclone open-array solid-state radars give sailors the confidence to tackle the toughest conditions, gain the upper hand in the hunt for fish, and confidently navigate busy waterways.
Cyclonic RadARs provide superior target separation and long-range resolution using CHIRP pulse compression and Raymarine beam sharpening technology. Each model features innovative sensing capabilities including Cyclone Bird Mode, RangeFusion™ technology and 60 RPM high-speed imaging.
ADVANCED DESIGN
- Airplane wing-inspired design is built for extremes with 100 knot wind resistance, the mebest in class, and designed to meet the commercial grade IEC 62388 standard for onboard radar
- At 13.1 inches (335 mm) high, the Cyclone's lower profile allows for greater flexibility boat architecture and more adaptable installation options.
- Innovative pedestal design conceals cable connections for a cleaner installation
THE ULTIMATE SITUATIONAL AWARENESS
- Fast 60 RPM rotation speed provides 360-degree awareness and accurate, real-time target tracking
- Doppler target tracking simplifies danger interpretation Bright, secure targets for added safety
- Professional-grade ARPA target tracking. Cyclone automatically tracks up to 50 targets using the same advanced ARPA technology trusted by the U.S. Coast Guard.
- RangeFusion™ technology combines short pulsesand long range in a single high-clarity radar image, providing exceptional range and range. long-range targets simultaneously.
FISHING INTELLIGENCE
- Optimized performance for locating seabirds
- Improved Bird Cyclone Mode using CHIRP pulse compression technology
6' OPEN ARRAY SIZE
- The 6' option provides superior separation and range of detection targets
In the E70621 stand box:
- Pro Pedestal
- Stud M10 x4
- Nut M10 x8
- Spring washer M10 x4
- Flat washer M10 x4
- Mounting joint
- Mounting model
- Radar data cable 15 m
- Power cable 15 m
- VCM100
- Cable clamp
- VCM100 mounting screws x2
- Cable clamp mounting screws x3
6' E70630 Antenna Box: - Antenna
- Threaded Alignment Guide
- Washer
- Washer spring loaded
- Nut
All Axiom displays require the upcoming LightHouse Hvar 3.16 software update for full compatibility with Cyclone. LightHouse Hvar 3.16 will be available in early November 2021.
PRODUCT ID: 91825
SKU: NVN-91825
CSKU: CWR-91825
REWRITE: 102936 -raymarine -cyclone-pro-radar-w-6-39-open-array
MPN: T70496
UPC: 723193836668
ASIN:
WSKU: RAYT70496
SSKU:
KSKU: RAYT70496
GSKU:
MSKU:
LSKU:
NAME: Raymarine Cyclone Pro Radar with 6FT Open Array and 15M Cables
NAME_EX: RAYMARINE CYCLONE PRO RADAR 6FT OPEN ARRAY WITH CABLE 15M
PTITLE: Raymarine Cyclone Pro Radar with 6' Open Array and 15M Cables
TYPE: Navigation and Marine Instruments | Radars
SELLER: Raymarine
GoogleCategory: ELECTRONICS> ELECTRONIQUE MARINE> MARINE RADAR
Gtags:
GSpecs:
Raymarine Cyclone Pro Radar with 6' Open Array and 15M Cables Product Description
With a powerful 110-watt solid-state transmitter, Cyclone Pro provides superior target separation and increased long-range resolution with CHIRP pulse compression and beam sharpening technology. The Cyclone Pro's increased power output is equivalent to a 12-kilowatt magnetron radar and gives the Cyclone Pro a range of up to 96 nautical miles. The Cyclone Pro model features innovative detection capabilities including Cyclone Bird Mode, RangeFusion™ technology, and 60 RPM high-speed imaging.
Raymarine T70496 Attributes- Radar Type: Open Array
- Size: 6 Foot Array
- Range: 96 nautical miles
- Rotation speed: 12 at 60 rpm
- PowerOutput: 110 watts
- Dimension: 15.27 inches length x 14.17 inches width x 13.18 inches in height
- Input voltage: 12 volts to 24 volts
- Width of beam: 1.32 degrees horizontal/25 degrees vertical
- Color: White
- Waterproof Rating: Waterproof Rating IPX6
- Includes: Radar Pedestal/Converter Voltage Cable / Power Cable / Data Cable / Mounting Kit
- Inspired by airplane wings: designed for extreme conditions with best-in-class 100 knot wind rating
- The Cyclone's lower profile allows for greater boat architecture flexibility and more adaptable installation options
- The Cyclone automatically tracks up to 50targets using the same advanced Arpa technology trusted by the United States Coast Guard
- RangeFusion™ Technology combines short and long pulses into a single, high-clarity radar image, providing exceptional range to short and long range targets simultaneously
- Fast 60 RPM rotation speed provides 360-degree awareness and precise real-time target tracking
- Tracks targets Doppler targets simplify interpretation of dangerous and safe targets for added safety
- Innovative pedestal design conceals cable connections for cleaner installation
- 6 foot option of Cyclone offers superior target separation and range detection
- 2-year limited warranty
- Cyclone Installation Instructions Cyclone Pro 87402 (Rev 5) (EN).pdf
- Raymarine-Global-Limited -Warranty-01-Jul-17-rev1-0.pdf
- Cyclone Installation Instructions Cyclone Pro 87402 (Rev 5) (EN).pdf
- 36 inch open die E70628 E70620 E70621 E70622 2D PDF.pdf
- 36 inch open die E70628 E70620 E70621 E70622 2D PDF.pdf
Cyclone Pro Radar 110 W with 6' open array and 15 m cables
OPEN ARRAY RADAR IN STATE TOUGH
The ultimate expression of design, rugged performance, and unmatched situational awareness, Cyclone solid-state open array radars give sailors the confidence to confront the harshest conditions, gain the upper hand in the hunt for fish, and confidently navigate busy waterways.
Cyclone radars provide superior target separation and long-range resolution thanks toCHIRP pulse compression and Raymarine beam sharpening technology. Each model features innovative sensing capabilities including Cyclone Bird Mode, RangeFusion™ technology and 60 RPM high-speed imaging.
ADVANCED DESIGN
- Aircraft wing-inspired design is built for extremes with best-in-class 100 knot wind resistance and built to meet commercial grade IEC 62388 for onboard radars
- At 13.1 inches (335 mm) tall, the Cyclone's lower profile allows for greater boat architecture flexibility and more adaptable installation options.
- Innovative pedestal design conceals cable connections for a cleaner installation
ULTIMATE SITUATIONAL AWARENESS
- Fast 60 RPM rotation speed provides 360-degree awareness and trackingaccurate real-time target tracking
- Doppler target tracking simplifies interpretation of dangerous and safe targets for increased safety
- Professional-grade ARPA target tracking. Cyclone automatically tracks up to 50 targets using the same advanced ARPA technology trusted by the U.S. Coast Guard.
- RangeFusion™ technology combines short and long pulses into one image Unique high clarity radar, providing exceptional range and range. long-range targets simultaneously.
FISHING INTELLIGENCE
- Optimized performance for locating seabirds
- Improved Bird Cyclone Mode using CHIRP pulse compression technology
6' OPEN ARRAY SIZE
- 6' option provides superior target separation and range detections
In the E70621 Stand Box:
- Pro Pedestal
- M10 Stud x4
- M10 Nut x8
- M10 Spring Washer x4
- li>
- Flat washer M10 x4
- Mounting gasket
- Mounting template
- Radar data cable 15m
- 15m power cable
- VCM100
- Cable clamp
- VCM100 mounting screws x2
- Cable clamp mounting screws x3
6' antenna box E70630: - Antenna
- Threaded Alignment Guide
- Washer
- Spring Washer
- Nut
All Axiom displays require next update Updated LightHouse Hvar 3.16 software for full compatibility with Cyclone. LightHouse Hvar 3.16 will be available in early November 2021.
Raymarine Cyclone Pro radar with 6' open array and 15m cables Related productsRaymarine 15m data cable f/ CycRadar solitaire
Frequently asked questions (FAQ) aboutThe Raymarine Cyclone Pro radar with 6' open array and 15m cables Who is the Raymarine?
How to describe the Raymarine Cyclone Pro radar with 6' open array and 15m cables?
What is the output voltage?
What is the size?
What is the color of the Raymarine Cyclone Pro radar with 6' open array and 15m cables? ?
What is the waterproof rating of the product?
What is the size of the product?
What is the maximum range (miles) of the product?
What is the Raymarine ? Raymarine, world leader in marine electronics, develops and manufactures the most complete range of electronic equipment. Raymarine is dedicated to the design, manufacture and distribution of the highest quality marine electronic products and services to the recreational and light commercial markets worldwide. Whether stand-alone units or fully integrated systems,Raymarine understands navigationon pleasure and what it takes to make it safer. How to describe the Raymarine Cyclone Pro radar with 6' open array and 15M cables? "
Raymarine cyclone radar 110 watts with 6 ft antenna
Model: T70496The ultimate expression of design, robust performance and knowledge of Unmatched, Cyclone solid-state open radars give sailors the confidence to tackle the toughest conditions, gain the upper hand in the hunt for fish, and confidently navigate busy waterways.
Cyclone radars offerSuperior target separation and long distance. range resolution using CHIRP pulse compression and Raymarine beam sharpening technology. Each model features innovative sensing capabilities including Cyclone Bird Mode, RangeFusion™ technology and 60 RPM high-speed imaging.
Specifications| Supply voltage (with VCM100) | Nominal: 12 V DC or 24 V DC / Minimum: 10.2 V DC / Maximum: 31.2 V DC |
| Power consumption (typical) | 95 watts |
| Power consumption (max) | 195 watts |
| Power consumption (standby) | 28 watts |
| Maximum range scale | 96 nm |
| Startup time | 40 seconds |
| Standbyto transmit | less than 5 seconds |
| Waterproof rating | IPX6 |
| Operating temperature range | -25°C to +55°C (-13°F to 131°F) |
| Humidity | Up to 93% at 40°C (104°F) |
| Maximum wind speed | 100 Kts |
| PowConnection | 1x Power connector |
| Data connection | 1x RayNet connector |
| Transmitter frequency | 9370, 9400, 9430 MHz (user selectable) |
| Transmitter power peak output | 110 watts |
| Receiver characteristic | Linear |
| Receiver noise | Less than 5 dB |
| Pedestal | |
| Dimensions | 388 mm x 360 mm x 335 mm / 15.27 in x 14.17 in x 13.18 in (to top of antenna) |
| Weight | 16 Kg |
| Antenna | |
| Beam width (vertical) | 25 degrees |
| Beam width (horizontal) | 1.32 degrees |
| Polarization | Horizontal |
| Speed of rotation | 12, 24, 36, 48, 60 rpm |
| Length | 1945 mm / 76.57 in |
| Weight | 12 Kg / 26.45 lb |
What's in the box:
- Cyclone Pro 110W Radar with 6' Open Array and 15M Cables
- Solid-state open array radar providing unmatched situational awareness
- The ultimate expression of design, rugged performance and unmatched situational awareness
- The Cyclone Pro 110W radar is the ultimate expression of robust design, performance and unrivaled situational awareness.
- Thanks to its fully open design, this radar is capable of detecting targets at distances greater than would be possible with an antenna traditional rotary.
- Its high performance and reliability make it an ideal choice for professional sailors who demand the best.
- The Cyclone Pro radar is the 'ultimate expression of design, rugged performance and unmatched situational awareness.
- Solid-state open array radars give mariners the confidence to navigate safely and confidently in all conditions.
- Cyclone Pro radar provides a powerful tool for safe navigation.
- Cyclone Pro 110W Radar with 6' Open Array and 15M Cables
- Solid-State Open Array Radar Delivers Unmatched Situational Awareness
- The ultimate expression of design, rugged performance and unmatched situational awareness
- The Cyclone Pro 110W radar is the ultimate expression of design, rugged performance and unmatched situational awareness. unrivaled situation.
- With its fully open design, this radar is capable of detecting targets at distances greater than what would be possible with a traditional rotating antenna.
- Its high performance and its reliability makes it an ideal choice for professional mariners who demand the best.
- Cyclone Pro radar is the ultimate expression of design, rugged performance and unmatched situational awareness.
- Solid-state open array radarsgive sailors the confidence to navigate safely and confidently in all conditions. li>
- Cyclone Pro Radar provides a powerful tool for safe navigation.
Buy the best price Raymarine Cyclone Pro Radar with 6' Open Array and 15M Cables for only $9,749 at NVN Marine ! Free same day delivery before 3 p.m. Raymarine Cyclone Pro Radar with 6' Open Array and 15M Cables Technical Specifications
| Type: | Marine Navigation and Instruments | Radars |
|---|---|
| Supplier: | Raymarine |
| Bay Size (inches): | 6FT |
| Power - Output: | 110W |
| Range - Max (miles): | 96NM |
| Product brochure: | Download PDF |
