CountyLine Electric Cast Iron Deep Well/Convertible Jet Pump 1 HP 115/230 Volt 14.8 GPM Well Pumps Home Improvement

The CountyLine 1 HP Cast-Iron Deep/Convertible Well Jet Pump delivers superior performance at depths to water of 70 ft. or less. Featuring rugged cast-iron construction and a heavy-duty, dual-voltage motor, this jet pump is designed for long-lasting, reliable use. To install the jet pump, plumbing skills are required.

Convertible operation: shallow well or deep well
Powered by a heavy-duty, 1/2 HP dual-voltage motor
Jet pump delivers superior performance at depths to water of 70 ft. or less
Rugged cast-iron construction ensures lasting use
Moderate level installation (plumbing skills required)
Includes ejector kit
For operation, a check valve, hacksaw, screwdriver, fuse box or circuit breaker, adjustable wrench, well seal, pipe wrench, tank tee, PVC cement and pressure tank may be needed (sold separately)
Backed by a 2-year warranty

CountyLine Electric Cast Iron Deep Well/Convertible Jet Pump 1 HP 115/230 Volt 14.8 GPM Well Pumps Home Improvement> Plumbing> Well Parts & Repair> Well Pumps

Specification	Description
Brand	CountyLine
Country of Origin	Imported
Amperage	11.9 Amp -6 Amp
Body Material	Cast iron
Compatible Pipe Material	PVC
Compatible Well Diameter	4 in.
Discharge Connection	Threaded Female
Discharge Diameter	1 in.
Discharge Rate at 0 ft.	14.8 GPM
Discharge Rate at 25 ft.	8.7 GPM
Discharge Rate at 50 ft.	5 GPM
Features	1 HP - pumps up to 9.0-14.8 GPM Dual Voltage- 115/230V (Factory set at 230V) Built-in Overload Motor, Well Injector Kit included (Well Injector Casting, Jet Nozzle, Venturi Tubes,and Hardware) 1-1/4 in. Suction, 1 in. Discharge
Horsepower	1 HP
Inlet Connection	Threaded Female
Inlet Diameter	1.25 in.
Maximum Flow Rate	14.8 GPM
Maximum Head Lift	90 ft.
Maximum Operating Depth	90 ft.
Maximum Operating Temperature	104 deg. F
Minimum Operating Temperature	33 deg. F
Power Type	Electric
Product Height	13.15 in.
Product Length	21.65 in.
Product Weight	46.74 lb.
Product Width	11.57 in.
Motor Type	PSC
Voltage	115-230V
Warranty	2 year
Manufacturer PartNumber	CL10CWJ
