GPI 1/10 HP 12V EZ-8-METHANOL-PO Methanol Fuel Transfer Pump 8 GPM Fuel Transfer Pumps Truck & Automotive

This GPI 12V 8 GPM EZ-8-METHANOL-PO Methanol Fuel Transfer Pump features a rotary gear design and is made from durable, lightweight cast aluminum. The 12VDC motor delivers gas station equivalent flow rates (up to 8 GPM (30 LPM)) for dispensing methanol. And the nickel plated housing prevents corrosion. This methanol pump is ideal for on the go fueling for agricultural and automotive applications and is the pump of choice for refueling recreational vehicles. The pump also features a convenient spin collar mount and includes a 15 ft. (4.6 m) power cord. Motor U.L. Listed to U.S. and Canadian Standards. 2 year warranty.

Fuel transfer pump features a nickel-plated housing for methanol usage
Self-priming low maintenance design makes the fuel pump easy to take care of
Convenient spin collar for easy installation and versatile pump mounting
Powder-coat, lightweight aluminum body provides corrosion resistance and reduces tank stress
Designed for permanent mounting on vented storage tanks
Thermal overload protection extends pump life
Motor U.L. listed to U.S. and Canadian standards
2 year warranty
Made in USA
Duty cycle is 15 min. on, 30 min. off
5.5 ft. maximum head lift
8 GPM maximum flow rate

GPI 1/10 HP 12V EZ-8-METHANOL-PO Methanol Fuel Transfer Pump 8 GPM Fuel Transfer Pumps Truck & Automotive> Fuel Transfer Tanks & Pumps> Fuel Transfer Pumps

Specification	Description
Brand	GPI
Country of Origin	Made in USA
AC or DC Powered	DC
Amperage	11A
Body Materials	Aluminum
Compatible Fluids	Methanol
Discharge Connection	Threaded Female
Discharge Diameter	0.75 in.
Duty Cycle	15 min. on, 30 min. off
Features	Self-Priming
Horsepower	1/10 HP
Hose Diameter	34 in. FNPT Outlet - Dispensing Hose Sold Seperately
Inlet Connection	Threaded Female
Inlet Diameter	1 in.
Intended Use Grade	Residential
Maximum Flow Rate	8 GPM
Maximum Head Lift	5.5 ft.
Maximum Operating Pressure	15 PSI 1.03 bar
Maximum Operating Temperature	125 deg. F 52 deg. C
Minimum Operating Pressure	15 PSI 1.03 bar
Minimum Operating Temperature	-20 deg. F -29 deg. C
Power Cord Length	15 ft.
Power Type	12 Volt
Product Height	7 in.
Product Length	7.5 in.
Product Weight	10.6 in.
Product Width	6.98 in.
Voltage	12V
Warranty	2 Year Limited
Manufacturer PartNumber	137700-01

GPI 1/10 HP 12V EZ-8-METHANOL-PO Methanol Fuel Transfer Pump, 8 GPM Specifications expand/collapse Specification Description Brand GPI Country of Origin Made in USA AC or DC Power Supply DC Amps 11 A Body Materials Aluminum Compatible Fluids Methanol Discharge Connection Female Threaded Discharge Diameter 0.75 in. Duty cycle 15 min. on, 30 min. Features Self-priming power 1/10 HP Hose diameter 34 in. FNPT Outlet - Distribution Hose Sold Separately Inlet Connection Female Threaded Inlet Diameter 1 in. Intended Use Residential Grade Maximum Flow Rate 8 GPM Maximum Head Lift 5.5 feet Maximum Operating Pressure 15 PSI 1.03 bar Maximum Operating Temperature 125 degrees. F 52 degrees. C Minimum operating pressure 15 PSI 1.03 bar Minimum operating temperature -20 deg. F -29 degrees. C Power cord length 15 feet Power type 12 volts Product height 7 inches Product length 7.5 inches Product weight 10.6 inches Product widthoduct 6.98 inch Voltage 12V 2-year limited warranty Manufacturer part number 137700-01
