Maxim Welded WSB Swivel Ball Hydraulic Cylinder 1 in Bore x 6 in Stroke 0.625 in Rod Diameter Hydraulic Cylinders Tractor Repair & Parts
The Maxim 1 in. Bore x 6 in. Stroke WSB Swivel Ball Welded Hydraulic Cylinder features swivel ball mounts, which make it great for use on compact equipment. The swivel ball hydraulic cylinder is designed for demanding applications and comes built to ensure maximum reliability and performance. A truly versatile design, this hydraulic cylinder is intended for double-acting applications, and it performs in those applications masterfully.- Intended use of swivel ball hydraulic cylinder: double-acting applications
- Piston: ductile iron
- Piston lock nut: nylock nut
- Gland: ductile iron with rod wear band
- Steel tube honed or skived for extended seal life
- Tube seal: O-ring and backup
- Ground and polished hard chrome-plated rod for durability
- Rod seal: U-cup
- Wiper: polyurethane
- End mounts: spherical
- All seals are manufactured to US specifications
- Ports: O-ring boss
- Paint: black
- 1 in. bore hydraulic cylinder with 6 in. strokes
- Measures 12 in. retracted and 18 in. extended
- Column load: 2,350 lb.
- Pin diameter of 0.5 in. and rod diameter of 0.625 in.
- 1 year warranty
- Maximum PSI: 3,000 PSI
- OD: 2 in.
- Width: 1 in.
Maxim Welded WSB Swivel Ball Hydraulic Cylinder 1 in Bore x 6 in Stroke 0.625 in Rod Diameter Hydraulic Cylinders Farm & Ranch> Tractor Parts & Accessories> Tractor Repair & Parts> Tractor Hydraulics> Hydraulic Cylinders
| Specification | Description |
|---|---|
| Brand | Maxim |
| Country of Origin | Imported |
| Bore Diameter | 1 in. |
| Brand Compatibility | Universal |
| Compatibility | Universal |
| Extended Length | 18 in. |
| Hydraulic Cylinder Type | Welded |
| Maximum Operating Pressure | 3,000 PSI |
| Maximum Weight Capacity | 2,350 lb. |
| Model Compatibility | Universal |
| Package Quantity | 1 |
| Pin Diameter | 0-1/2 in. |
| Port Size | SAE 6 |
| Primary Material | Steel |
| Product Height | N/A |
| Product Length | N/A |
| Product Weight | 5 lb. |
| Product Width | N/A |
| Retracted Length | 12 in. |
| Rod Diameter | 2 in. |
| Single/Double Acting | Double acting |
| Stroke Distance | 6 in. |
| Warranty | 1 Year |
| Manufacturer PartNumber | 400501 |
